Brand |
KF |
|
Finish/Coating |
Tinned |
|
Base Materials |
Copper |
|
Insulation Material |
N/A |
|
Brazed |
Seam |
|
Wire/Cable Type |
Regular Wire |
|
Color Code |
Standard |
|
MOQ |
1000Pcs/item |
|
Payment Terms |
Based on orders |
|
Delivery |
FOB/CIF/DDP |
| Spec (American AWG) | 10 | 8 | 6 | 4 | 2 | 1/0 | 2/0 | 3/0 | 4/0 | 250/300MCM | 300/350MCM | 400MCM | 500MCM | 600/750MCM |
| Spec (JIS AWG) | 6 | 10 | 16 | 25 | 35 | 50 | 70 | 95 | 120 | 150 | 185 | 240 | 300 | 400 |
| Spec (DIN AWG) | ||||||||||||||
| Spec (GB mm2) | ||||||||||||||
| Max Current | 50 | 70 | 95 | 125 | 170 | 230 | 265 | 310 | 360 | 445 | 505 | 545 | 620 | 785 |
You can tick the products you need and communicate with us in the message board.
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions Inch | Tool | PCS/Pack | |||||
| USA | d2 | L1 | L2 | D | d | B | ||||||
| A.W.G. 10 | KFLW910 | 10 AWG Copper Tubular Lugs (Type WB 90°) WB90-6/5 | WB90-5 | #10 | 0.209 | 0.886 | 0.551 | 0.256 | 0.138 | 0.413 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFLW911 | 10 AWG Copper Tubular Lugs (Type WB 90°) WB90-6/6 | WB90-6 | 1/4" | 0.252 | 0.945 | 0.551 | 0.256 | 0.138 | 0.472 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFLW912 | 10 AWG Copper Tubular Lugs (Type WB 90°) WB90-6/8 | WB90-8 | 5/16" | 0.335 | 1.083 | 0.551 | 0.256 | 0.138 | 0.591 | IZUMI 5N18 | 500 |
| A.W.G. 10 | KFLW913 | 10 AWG Copper Tubular Lugs (Type WB 90°) WB90-6/10 | WB90-10 | 3/8" | 0.413 | 1.161 | 0.551 | 0.256 | 0.138 | 0.630 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLW920 | 8 AWG Copper Tubular Lugs (Type WB 90°) WB90-10/5 | WB90-10-5 | #10 | 0.209 | 0.906 | 0.630 | 0.276 | 0.177 | 0.472 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLW921 | 8 AWG Copper Tubular Lugs (Type WB 90°) WB90-10/6 | WB90-10-6 | 1/4" | 0.252 | 0.945 | 0.630 | 0.276 | 0.177 | 0.472 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLW922 | 8 AWG Copper Tubular Lugs (Type WB 90°) WB90-10/8 | WB90-10-8 | 5/16" | 0.335 | 1.102 | 0.630 | 0.276 | 0.177 | 0.591 | IZUMI 5N18 | 500 |
| A.W.G. 8 | KFLW923 | 8 AWG Copper Tubular Lugs (Type WB 90°) WB90-10/10 | WB90-10-10 | 3/8" | 0.413 | 1.161 | 0.630 | 0.276 | 0.177 | 0.709 | IZUMI 5N18 | 500 |
| A.W.G. 6 | KFLW930 | 6 AWG Copper Tubular Lugs (Type WB 90°) WB90-16/5 | WB90-16-6 | #10 | 0.209 | 0.886 | 0.787 | 0.335 | 0.217 | 0.472 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLW931 | 6 AWG Copper Tubular Lugs (Type WB 90°) WB90-16/6 | WB90-16-8 | 1/4" | 0.252 | 0.945 | 0.787 | 0.335 | 0.217 | 0.551 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLW932 | 6 AWG Copper Tubular Lugs (Type WB 90°) WB90-16/8 | WB90-16-10 | 5/16" | 0.335 | 1.102 | 0.787 | 0.335 | 0.217 | 0.591 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLW933 | 6 AWG Copper Tubular Lugs (Type WB 90°) WB90-16/10 | WB90-16-8 | 3/8" | 0.413 | 1.220 | 0.787 | 0.335 | 0.217 | 0.709 | OPT TP-150D | 500 |
| A.W.G. 6 | KFLW934 | 6 AWG Copper Tubular Lugs (Type WB 90°) WB90-16/12 | WB90-16-10 | 1/2" | 0.512 | 1.260 | 0.787 | 0.335 | 0.217 | 0.748 | OPT TP-150D | 500 |
| A.W.G. 4 | KFLW940 | 4 AWG Copper Tubular Lugs (Type WB 90°) WB90-25/6 | WB90-25/6 | 1/4" | 0.252 | 1.083 | 0.827 | 0.394 | 0.272 | 0.591 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLW941 | 4 AWG Copper Tubular Lugs (Type WB 90°) WB90-25/8 | WB90-25/8 | 5/16" | 0.331 | 1.280 | 0.827 | 0.394 | 0.272 | 0.630 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLW942 | 4 AWG Copper Tubular Lugs (Type WB 90°) WB90-25/10 | WB90-25/10 | 3/8" | 0.413 | 1.280 | 0.827 | 0.394 | 0.272 | 0.709 | OPT TP-150D | 250 |
| A.W.G. 4 | KFLW943 | 4 AWG Copper Tubular Lugs (Type WB 90°) WB90-25/12 | WB90-25/12 | 1/2" | 0.512 | 1.339 | 0.827 | 0.394 | 0.272 | 0.748 | OPT TP-150D | 250 |
| A.W.G. 2 | KFLW950 | 2 AWG Copper Tubular Lugs (Type WB 90°) WB90-35/6 | WB90-35/6 | 1/4" | 0.252 | 1.122 | 0.945 | 0.472 | 0.335 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLW951 | 2 AWG Copper Tubular Lugs (Type WB 90°) WB90-35/8 | WB90-35/8 | 5/16" | 0.335 | 1.339 | 0.945 | 0.472 | 0.335 | 0.669 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLW952 | 2 AWG Copper Tubular Lugs (Type WB 90°) WB90-35/10 | WB90-35/10 | 3/8" | 0.413 | 1.339 | 0.945 | 0.472 | 0.335 | 0.787 | OPT TP-150D | 200 |
| A.W.G. 2 | KFLW953 | 2 AWG Copper Tubular Lugs (Type WB 90°) WB90-35/12 | WB90-35/12 | 1/2" | 0.512 | 1.594 | 0.945 | 0.472 | 0.335 | 0.866 | OPT TP-150D | 200 |
| A.W.G. 1/0 | KFLW960 | 1/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-50/6 | WB90-50/6 | 1/4" | 0.252 | 1.457 | 1.122 | 0.551 | 0.394 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLW961 | 1/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-50/8 | WB90-50/8 | 5/16" | 0.331 | 1.594 | 1.122 | 0.551 | 0.394 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLW962 | 1/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-50/10 | WB90-50/10 | 3/8" | 0.413 | 1.594 | 1.122 | 0.551 | 0.394 | 0.787 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLW963 | 1/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-50/12 | WB90-50/12 | 1/2" | 0.512 | 1.673 | 1.122 | 0.551 | 0.394 | 0.906 | OPT TP-150D | 100 |
| A.W.G. 1/0 | KFLW964 | 1/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-50/16 | WB90-50/16 | 5/8" | 0.669 | 1.988 | 1.122 | 0.551 | 0.394 | 1.102 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLW970 | 2/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-70/8 | WB90-70/8 | 5/16" | 0.335 | 1.693 | 1.220 | 0.650 | 0.472 | 0.945 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLW971 | 2/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-70/10 | WB90-70/10 | 3/8" | 0.413 | 1.693 | 1.220 | 0.650 | 0.472 | 0.945 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLW972 | 2/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-70/12 | WB90-70/12 | 1/2" | 0.512 | 1.752 | 1.220 | 0.650 | 0.472 | 0.945 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLW973 | 2/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-70/16 | WB90-70/16 | 5/8" | 0.669 | 2.087 | 1.220 | 0.650 | 0.472 | 1.102 | OPT TP-150D | 100 |
| A.W.G. 2/0 | KFLW974 | 2/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-70/20 | WB90-70/20 | 3/4" | 0.827 | 2.323 | 1.220 | 0.650 | 0.472 | 1.181 | OPT TP-150D | 100 |
| A.W.G. 3/0 | KFLW980 | 3/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-95/8 | WB90-95/8 | 5/16" | 0.335 | 1.752 | 1.378 | 0.709 | 0.531 | 1.024 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLW981 | 3/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-95/10 | WB90-95/10 | 3/8" | 0.413 | 1.752 | 1.378 | 0.709 | 0.531 | 1.024 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLW982 | 3/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-95/12 | WB90-95/12 | 1/2" | 0.512 | 1.831 | 1.378 | 0.709 | 0.531 | 1.024 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLW983 | 3/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-95/16 | WB90-95/16 | 5/8" | 0.669 | 2.047 | 1.378 | 0.709 | 0.531 | 1.102 | OPT TP-150D | 50 |
| A.W.G. 3/0 | KFLW984 | 3/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-95/20 | WB90-95/20 | 3/4" | 0.827 | 2.323 | 1.378 | 0.709 | 0.531 | 1.201 | OPT TP-150D | 50 |
| A.W.G. 4/0 | KFLW990 | 4/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-120/10 | WB90-120/10 | 3/8" | 0.413 | 1.929 | 1.398 | 0.768 | 0.591 | 1.142 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLW991 | 4/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-120/12 | WB90-120/12 | 1/2" | 0.512 | 1.929 | 1.398 | 0.768 | 0.591 | 1.142 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLW992 | 4/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-120/16 | WB90-120/16 | 5/8" | 0.669 | 2.165 | 1.398 | 0.768 | 0.591 | 1.142 | IZUMI EP-520C | 30 |
| A.W.G. 4/0 | KFLW993 | 4/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-120/20 | WB90-120/20 | 3/4" | 0.827 | 2.402 | 1.398 | 0.768 | 0.591 | 1.201 | IZUMI EP-520C | 30 |
| A.W.G. 250/300MCM | KFLW9A0 | 250/300MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-150/10 | WB90-150/10 | 3/8" | 0.413 | 1.890 | 1.575 | 0.827 | 0.650 | 1.220 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLW9A1 | 250/300MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-150/12 | WB90-150/12 | 1/2" | 0.512 | 2.008 | 1.575 | 0.827 | 0.650 | 1.220 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLW9A2 | 250/300MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-150/16 | WB90-150/16 | 5/8" | 0.669 | 2.205 | 1.575 | 0.827 | 0.650 | 1.220 | IZUMI EP-520C | 10 |
| A.W.G. 250/300MCM | KFLW9A3 | 250/300MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-150/20. | WB90-150/20 | 3/4" | 0.827 | 2.421 | 1.575 | 0.827 | 0.650 | 1.339 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLW9B0 | 300/350MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-185/12 | WB90-185/12 | 1/2" | 0.512 | 2.303 | 1.811 | 0.945 | 0.748 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLW9B1 | 300/350MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-185/16 | WB90-185/16 | 5/8" | 0.669 | 2.303 | 1.811 | 0.945 | 0.748 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 300/350MCM | KFLW9B2 | 300/350MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-185/20 | WB90-185/20 | 3/4" | 0.827 | 2.559 | 1.811 | 0.945 | 0.748 | 1.378 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLW9C0 | 400MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-240/12 | WB90-240/12 | 1/2" | 0.512 | 2.126 | 1.969 | 1.024 | 0.827 | 1.575 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLW9C1 | 400MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-240/16 | WB90-240/16 | 5/8" | 0.669 | 2.362 | 1.969 | 1.024 | 0.827 | 1.575 | IZUMI EP-520C | 10 |
| A.W.G. 400MCM | KFLW9C2 | 400MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-240/20 | WB90-240/20 | 3/4" | 0.827 | 2.669 | 1.969 | 1.024 | 0.827 | 1.575 | IZUMI EP-520C | 10 |
| A.W.G. 500MCM | KFLW9D0 | 500MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-300/12 | WB90-300/12 | 1/2" | 0.512 | 2.933 | 2.323 | 1.161 | 0.925 | 1.693 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLW9D1 | 500MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-300/16 | WB90-300/16 | 5/8" | 0.669 | 2.520 | 2.323 | 1.161 | 0.925 | 1.693 | IZUMI EP-1000A | 5 |
| A.W.G. 500MCM | KFLW9D2 | 500MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-300/20 | WB90-300/20 | 3/4" | 0.827 | 2.776 | 2.323 | 1.161 | 0.925 | 1.693 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLW9E0 | 600/750MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-400/12 | WB90-400/12 | 1/2" | 0.512 | 3.110 | 2.441 | 1.339 | 1.063 | 1.929 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLW9E1 | 600/750MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-400/16 | WB90-400/16 | 5/8" | 0.669 | 2.697 | 2.441 | 1.339 | 1.063 | 1.929 | IZUMI EP-1000A | 5 |
| A.W.G. 600/750MCM | KFLW9E2 | 600/750MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-400/20 | WB90-400/20 | 3/4" | 0.827 | 2.953 | 2.441 | 1.339 | 1.063 | 1.929 | IZUMI EP-1000A | 5 |
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions mm | Tool | PCS/Pack | |||||
| Meric | d2 | L1 | L2 | D | d | B | ||||||
| 6mm² | KFLW910 | 10 AWG Copper Tubular Lugs (Type WB 90°) WB90-6/5 | WB90-5 | 5 | 5.3 | 22.5 | 14.0 | 6.5 | 3.5 | 10.5 | IZUMI 5N18 | 500 |
| 6mm² | KFLW911 | 10 AWG Copper Tubular Lugs (Type WB 90°) WB90-6/6 | WB90-6 | 6 | 6.4 | 24.0 | 14.0 | 6.5 | 3.5 | 12.0 | IZUMI 5N18 | 500 |
| 6mm² | KFLW912 | 10 AWG Copper Tubular Lugs (Type WB 90°) WB90-6/8 | WB90-8 | 8 | 8.5 | 27.5 | 14.0 | 6.5 | 3.5 | 15.0 | IZUMI 5N18 | 500 |
| 6mm² | KFLW913 | 10 AWG Copper Tubular Lugs (Type WB 90°) WB90-6/10 | WB90-10 | 10 | 10.5 | 29.5 | 14.0 | 6.5 | 3.5 | 16.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLW920 | 8 AWG Copper Tubular Lugs (Type WB 90°) WB90-10/5 | WB90-10-5 | 5 | 5.3 | 23.0 | 16.0 | 7.0 | 4.5 | 12.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLW921 | 8 AWG Copper Tubular Lugs (Type WB 90°) WB90-10/6 | WB90-10-6 | 6 | 6.4 | 24.0 | 16.0 | 7.0 | 4.5 | 12.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLW922 | 8 AWG Copper Tubular Lugs (Type WB 90°) WB90-10/8 | WB90-10-8 | 8 | 8.5 | 28.0 | 16.0 | 7.0 | 4.5 | 15.0 | IZUMI 5N18 | 500 |
| 10mm² | KFLW923 | 8 AWG Copper Tubular Lugs (Type WB 90°) WB90-10/10 | WB90-10-10 | 10 | 10.5 | 29.5 | 16.0 | 7.0 | 4.5 | 18.0 | IZUMI 5N18 | 500 |
| 16mm² | KFLW930 | 6 AWG Copper Tubular Lugs (Type WB 90°) WB90-16/5 | WB90-16-6 | 6 | 5.3 | 22.5 | 20.0 | 8.5 | 5.5 | 12.0 | OPT TP-150D | 500 |
| 16mm² | KFLW931 | 6 AWG Copper Tubular Lugs (Type WB 90°) WB90-16/6 | WB90-16-8 | 8 | 6.4 | 24.0 | 20.0 | 8.5 | 5.5 | 14.0 | OPT TP-150D | 500 |
| 16mm² | KFLW932 | 6 AWG Copper Tubular Lugs (Type WB 90°) WB90-16/8 | WB90-16-10 | 10 | 8.5 | 28.0 | 20.0 | 8.5 | 5.5 | 15.0 | OPT TP-150D | 500 |
| 16mm² | KFLW933 | 6 AWG Copper Tubular Lugs (Type WB 90°) WB90-16/10 | WB90-16-8 | 8 | 10.5 | 31.0 | 20.0 | 8.5 | 5.5 | 18.0 | OPT TP-150D | 500 |
| 16mm² | KFLW934 | 6 AWG Copper Tubular Lugs (Type WB 90°) WB90-16/12 | WB90-16-10 | 10 | 13.0 | 32.0 | 20.0 | 8.5 | 5.5 | 19.0 | OPT TP-150D | 500 |
| 25mm² | KFLW940 | 4 AWG Copper Tubular Lugs (Type WB 90°) WB90-25/6 | WB90-25/6 | 6 | 6.4 | 27.5 | 21.0 | 10.0 | 6.9 | 15.0 | OPT TP-150D | 250 |
| 25mm² | KFLW941 | 4 AWG Copper Tubular Lugs (Type WB 90°) WB90-25/8 | WB90-25/8 | 8 | 8.4 | 32.5 | 21.0 | 10.0 | 6.9 | 16.0 | OPT TP-150D | 250 |
| 25mm² | KFLW942 | 4 AWG Copper Tubular Lugs (Type WB 90°) WB90-25/10 | WB90-25/10 | 10 | 10.5 | 32.5 | 21.0 | 10.0 | 6.9 | 18.0 | OPT TP-150D | 250 |
| 25mm² | KFLW943 | 4 AWG Copper Tubular Lugs (Type WB 90°) WB90-25/12 | WB90-25/12 | 12 | 13.0 | 34.0 | 21.0 | 10.0 | 6.9 | 19.0 | OPT TP-150D | 250 |
| 35mm² | KFLW950 | 2 AWG Copper Tubular Lugs (Type WB 90°) WB90-35/6 | WB90-35/6 | 6 | 6.4 | 28.5 | 24.0 | 12.0 | 8.5 | 17.0 | OPT TP-150D | 200 |
| 35mm² | KFLW951 | 2 AWG Copper Tubular Lugs (Type WB 90°) WB90-35/8 | WB90-35/8 | 8 | 8.5 | 34.0 | 24.0 | 12.0 | 8.5 | 17.0 | OPT TP-150D | 200 |
| 35mm² | KFLW952 | 2 AWG Copper Tubular Lugs (Type WB 90°) WB90-35/10 | WB90-35/10 | 10 | 10.5 | 34.0 | 24.0 | 12.0 | 8.5 | 20.0 | OPT TP-150D | 200 |
| 35mm² | KFLW953 | 2 AWG Copper Tubular Lugs (Type WB 90°) WB90-35/12 | WB90-35/12 | 12 | 13.0 | 40.5 | 24.0 | 12.0 | 8.5 | 22.0 | OPT TP-150D | 200 |
| 50mm² | KFLW960 | 1/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-50/6 | WB90-50/6 | 6 | 6.4 | 37.0 | 28.5 | 14.0 | 10.0 | 20.0 | OPT TP-150D | 100 |
| 50mm² | KFLW961 | 1/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-50/8 | WB90-50/8 | 8 | 8.4 | 40.5 | 28.5 | 14.0 | 10.0 | 20.0 | OPT TP-150D | 100 |
| 50mm² | KFLW962 | 1/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-50/10 | WB90-50/10 | 10 | 10.5 | 40.5 | 28.5 | 14.0 | 10.0 | 20.0 | OPT TP-150D | 100 |
| 50mm² | KFLW963 | 1/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-50/12 | WB90-50/12 | 12 | 13.0 | 42.5 | 28.5 | 14.0 | 10.0 | 23.0 | OPT TP-150D | 100 |
| 50mm² | KFLW964 | 1/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-50/16 | WB90-50/16 | 16 | 17.0 | 50.5 | 28.5 | 14.0 | 10.0 | 28.0 | OPT TP-150D | 100 |
| 70mm² | KFLW970 | 2/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-70/8 | WB90-70/8 | 8 | 8.5 | 43.0 | 31.0 | 16.5 | 12.0 | 24.0 | OPT TP-150D | 100 |
| 70mm² | KFLW971 | 2/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-70/10 | WB90-70/10 | 10 | 10.5 | 43.0 | 31.0 | 16.5 | 12.0 | 24.0 | OPT TP-150D | 100 |
| 70mm² | KFLW972 | 2/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-70/12 | WB90-70/12 | 12 | 13.0 | 44.5 | 31.0 | 16.5 | 12.0 | 24.0 | OPT TP-150D | 100 |
| 70mm² | KFLW973 | 2/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-70/16 | WB90-70/16 | 16 | 17.0 | 53.0 | 31.0 | 16.5 | 12.0 | 28.0 | OPT TP-150D | 100 |
| 70mm² | KFLW974 | 2/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-70/20 | WB90-70/20 | 20 | 21.0 | 59.0 | 31.0 | 16.5 | 12.0 | 30.0 | OPT TP-150D | 100 |
| 95mm² | KFLW980 | 3/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-95/8 | WB90-95/8 | 8 | 8.5 | 44.5 | 35.0 | 18.0 | 13.5 | 26.0 | OPT TP-150D | 50 |
| 95mm² | KFLW981 | 3/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-95/10 | WB90-95/10 | 10 | 10.5 | 44.5 | 35.0 | 18.0 | 13.5 | 26.0 | OPT TP-150D | 50 |
| 95mm² | KFLW982 | 3/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-95/12 | WB90-95/12 | 12 | 13.0 | 46.5 | 35.0 | 18.0 | 13.5 | 26.0 | OPT TP-150D | 50 |
| 95mm² | KFLW983 | 3/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-95/16 | WB90-95/16 | 16 | 17.0 | 52.0 | 35.0 | 18.0 | 13.5 | 28.0 | OPT TP-150D | 50 |
| 95mm² | KFLW984 | 3/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-95/20 | WB90-95/20 | 20 | 21.0 | 59.0 | 35.0 | 18.0 | 13.5 | 30.5 | OPT TP-150D | 50 |
| 120mm² | KFLW990 | 4/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-120/10 | WB90-120/10 | 10 | 10.5 | 49.0 | 35.5 | 19.5 | 15.0 | 29.0 | IZUMI EP-520C | 30 |
| 120mm² | KFLW991 | 4/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-120/12 | WB90-120/12 | 12 | 13.0 | 49.0 | 35.5 | 19.5 | 15.0 | 29.0 | IZUMI EP-520C | 30 |
| 120mm² | KFLW992 | 4/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-120/16 | WB90-120/16 | 16 | 17.0 | 55.0 | 35.5 | 19.5 | 15.0 | 29.0 | IZUMI EP-520C | 30 |
| 120mm² | KFLW993 | 4/0 AWG Copper Tubular Lugs (Type WB 90°) WB90-120/20 | WB90-120/20 | 20 | 21.0 | 61.0 | 35.5 | 19.5 | 15.0 | 30.5 | IZUMI EP-520C | 30 |
| 150mm² | KFLW9A0 | 250/300MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-150/10 | WB90-150/10 | 10 | 10.5 | 48.0 | 40.0 | 21.0 | 16.5 | 31.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLW9A1 | 250/300MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-150/12 | WB90-150/12 | 12 | 13.0 | 51.0 | 40.0 | 21.0 | 16.5 | 31.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLW9A2 | 250/300MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-150/16 | WB90-150/16 | 16 | 17.0 | 56.0 | 40.0 | 21.0 | 16.5 | 31.0 | IZUMI EP-520C | 10 |
| 150mm² | KFLW9A3 | 250/300MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-150/20. | WB90-150/20 | 20 | 21.0 | 61.5 | 40.0 | 21.0 | 16.5 | 34.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLW9B0 | 300/350MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-185/12 | WB90-185/12 | 12 | 13.0 | 58.5 | 46.0 | 24.0 | 19.0 | 35.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLW9B1 | 300/350MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-185/16 | WB90-185/16 | 16 | 17.0 | 58.5 | 46.0 | 24.0 | 19.0 | 35.0 | IZUMI EP-520C | 10 |
| 185mm² | KFLW9B2 | 300/350MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-185/20 | WB90-185/20 | 20 | 21.0 | 65.0 | 46.0 | 24.0 | 19.0 | 35.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLW9C0 | 400MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-240/12 | WB90-240/12 | 12 | 13.0 | 54.0 | 50.0 | 26.0 | 21.0 | 40.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLW9C1 | 400MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-240/16 | WB90-240/16 | 16 | 17.0 | 60.0 | 50.0 | 26.0 | 21.0 | 40.0 | IZUMI EP-520C | 10 |
| 240mm² | KFLW9C2 | 400MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-240/20 | WB90-240/20 | 20 | 21.0 | 67.8 | 50.0 | 26.0 | 21.0 | 40.0 | IZUMI EP-520C | 10 |
| 300mm² | KFLW9D0 | 500MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-300/12 | WB90-300/12 | 12 | 13.0 | 74.5 | 59.0 | 29.5 | 23.5 | 43.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFLW9D1 | 500MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-300/16 | WB90-300/16 | 16 | 17.0 | 64.0 | 59.0 | 29.5 | 23.5 | 43.0 | IZUMI EP-1000A | 5 |
| 300mm² | KFLW9D2 | 500MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-300/20 | WB90-300/20 | 20 | 21.0 | 70.5 | 59.0 | 29.5 | 23.5 | 43.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLW9E0 | 600/750MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-400/12 | WB90-400/12 | 12 | 13.0 | 79.0 | 62.0 | 34.0 | 27.0 | 49.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLW9E1 | 600/750MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-400/16 | WB90-400/16 | 16 | 17.0 | 68.5 | 62.0 | 34.0 | 27.0 | 49.0 | IZUMI EP-1000A | 5 |
| 400mm² | KFLW9E2 | 600/750MCM AWG Copper Tubular Lugs (Type WB 90°) WB90-400/20 | WB90-400/20 | 20 | 21.0 | 75.0 | 62.0 | 34.0 | 27.0 | 49.0 | IZUMI EP-1000A | 5 |
Want to get a sample? Please fill in the form, leave your contact information and parameter information.
