Brand |
KF |
|
Finish/Coating |
Tinned |
|
Base Materials |
Copper,PVC |
|
Insulation Material |
N/A |
|
Brazed |
Seam |
|
Wire/Cable Type |
Regular Wire |
|
Color Code |
Standard |
|
MOQ |
1000Pcs/item |
|
Payment Terms |
Based on orders |
|
Delivery |
FOB/CIF/DDP |
|
Spec (American AWG) |
22-16 | 16-14 | 12-10 |
|
Spec (JIS AWG) |
1.25 | 2 | 5.5 |
|
Spec (DIN AWG) |
1 | 2.5 | 4.0-6.0 |
|
Spec (GB mm2) |
0.5-1.5 | 2.5 | 6 |
|
Max Current |
19 | 27 | 48 |
| Operating Voltage | 600V | ||
| Temperature Withstand | 75℃ | ||
You can tick the products you need and communicate with us in the message board.
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions Inch | Color | Tool | PCS/Pack | ||||||
| USA | d2 | B | F | L | H | D | T | |||||||
| A.W.G. 22-16 | KFSE110 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-3 | SVE1.25-3 | #4 | 0.126 | 0.217 | 0.256 | 0.866 | 0.433 | 0.157 | 0.030 | Red | IZUMI 3# | 1000 |
| A.W.G. 22-16 | KFSE111 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-3.5 | SVES1.25-3.5 | #6 | 0.146 | 0.217 | 0.256 | 0.866 | 0.433 | 0.157 | 0.030 | Red | IZUMI 3# | 1000 |
| A.W.G. 22-16 | KFSE112 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-3.5 | SVEL1.25-3.5 | #6 | 0.146 | 0.256 | 0.256 | 0.866 | 0.433 | 0.157 | 0.030 | Red | IZUMI 3# | 1000 |
| A.W.G. 22-16 | KFSE113 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-4 | SVES1.25-4 | #8 | 0.169 | 0.256 | 0.256 | 0.866 | 0.433 | 0.157 | 0.030 | Red | IZUMI 3# | 1000 |
| A.W.G. 22-16 | KFSE114 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-4 | SVEM1.25-4 | #8 | 0.169 | 0.276 | 0.256 | 0.866 | 0.433 | 0.157 | 0.030 | Red | IZUMI 3# | 1000 |
| A.W.G. 22-16 | KFSE115 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-4 | SVEL1.25-4 | #8 | 0.169 | 0.315 | 0.256 | 0.866 | 0.433 | 0.157 | 0.030 | Red | IZUMI 3# | 1000 |
| A.W.G. 22-16 | KFSE116 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-5 | SVES1.25-5 | #10 | 0.209 | 0.315 | 0.256 | 0.866 | 0.433 | 0.157 | 0.030 | Red | IZUMI 3# | 1000 |
| A.W.G. 22-16 | KFSE117 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-5 | SVEL1.25-5 | #10 | 0.209 | 0.374 | 0.256 | 0.866 | 0.433 | 0.157 | 0.030 | Red | IZUMI 3# | 1000 |
| A.W.G. 22-16 | KFSE118 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-6 | SVES1.25-6 | 1/4" | 0.252 | 0.374 | 0.256 | 0.866 | 0.433 | 0.157 | 0.030 | Red | IZUMI 3# | 1000 |
| A.W.G. 22-16 | KFSE119 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-6 | SVEL1.25-6 | 1/4" | 0.252 | 0.472 | 0.433 | 1.102 | 0.433 | 0.157 | 0.030 | Red | IZUMI 3# | 1000 |
| A.W.G. 16-14 | KFSE120 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-3 | SVE2-3 | #4 | 0.126 | 0.217 | 0.256 | 0.886 | 0.453 | 0.177 | 0.031 | Blue | IZUMI 4# | 1000 |
| A.W.G. 16-14 | KFSE121 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-3.5 | SVES2.-3.5 | #6 | 0.146 | 0.217 | 0.256 | 0.886 | 0.453 | 0.177 | 0.031 | Blue | IZUMI 4# | 1000 |
| A.W.G. 16-14 | KFSE122 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-3.5 | SVEL2-3.5 | #6 | 0.146 | 0.276 | 0.256 | 0.886 | 0.453 | 0.177 | 0.031 | Blue | IZUMI 4# | 1000 |
| A.W.G. 16-14 | KFSE123 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-4 | SVES2-4 | #8 | 0.169 | 0.256 | 0.256 | 0.886 | 0.453 | 0.177 | 0.031 | Blue | IZUMI 4# | 1000 |
| A.W.G. 16-14 | KFSE124 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-4 | SVEM2-4 | #8 | 0.169 | 0.276 | 0.256 | 0.886 | 0.453 | 0.177 | 0.031 | Blue | IZUMI 4# | 1000 |
| A.W.G. 16-14 | KFSE125 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-4 | SVEL2-4 | #8 | 0.169 | 0.315 | 0.256 | 0.886 | 0.453 | 0.177 | 0.031 | Blue | IZUMI 4# | 1000 |
| A.W.G. 16-14 | KFSE126 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-5 | SVES2-5 | #10 | 0.209 | 0.315 | 0.256 | 0.886 | 0.453 | 0.177 | 0.031 | Blue | IZUMI 4# | 1000 |
| A.W.G. 16-14 | KFSE127 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-5 | SVEL2-5 | #10 | 0.209 | 0.374 | 0.256 | 0.886 | 0.453 | 0.177 | 0.031 | Blue | IZUMI 4# | 1000 |
| A.W.G. 16-14 | KFSE128 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-6 | SVES2-6 | 1/4" | 0.252 | 0.374 | 0.256 | 0.886 | 0.453 | 0.177 | 0.031 | Blue | IZUMI 4# | 1000 |
| A.W.G. 16-14 | KFSE129 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-6 | SVEL2-6 | 1/4" | 0.252 | 0.472 | 0.433 | 1.122 | 0.453 | 0.177 | 0.031 | Blue | IZUMI 4# | 1000 |
| A.W.G. 12-10 | KFSE130 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-3.5 | SVE5.5-3.5 | #6 | 0.146 | 0.335 | 0.295 | 1.043 | 0.551 | 0.256 | 0.039 | Yellow | IZUMI 5# | 1000 |
| A.W.G. 12-10 | KFSE131 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-4 | SVES5.5-4 | #8 | 0.169 | 0.335 | 0.295 | 1.043 | 0.551 | 0.256 | 0.039 | Yellow | IZUMI 5# | 1000 |
| A.W.G. 12-10 | KFSE132 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-4 | SVEL5.5-4 | #8 | 0.169 | 0.374 | 0.295 | 1.043 | 0.551 | 0.256 | 0.039 | Yellow | IZUMI 5# | 1000 |
| A.W.G. 12-10 | KFSE133 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-5 | SVE5.5-5 | #10 | 0.209 | 0.354 | 0.295 | 1.043 | 0.551 | 0.256 | 0.039 | Yellow | IZUMI 5# | 1000 |
| A.W.G. 12-10 | KFSE134 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-6 | SVES5.5-6 | 1/4" | 0.252 | 0.354 | 0.295 | 1.043 | 0.551 | 0.256 | 0.039 | Yellow | IZUMI 5# | 1000 |
| A.W.G. 12-10 | KFSE135 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-6 | SVEL5.5-6 | 1/4" | 0.252 | 0.472 | 0.472 | 1.28 | 0.551 | 0.256 | 0.039 | Yellow | IZUMI 5# | 1000 |
| A.W.G. 12-10 | KFSE136 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-8 | SVE5.5-8 | 5/16" | 0.331 | 0.551 | 0.453 | 1.24 | 0.551 | 0.256 | 0.039 | Yellow | IZUMI 5# | 1000 |
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions mm | Color | Tool | PCS/Pack | ||||||
| Meric | d2 | B | F | L | H | D | T | |||||||
| 0.5~1.5mm² | KFSE110 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-3 | SVE1.25-3 | 3 | 3.2 | 5.5 | 6.5 | 22.0 | 11.0 | 4.0 | 0.75 | Red | IZUMI 3# | 1000 |
| 0.5~1.5mm² | KFSE111 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-3.5 | SVES1.25-3.5 |
3.5 |
3.7 | 5.5 | 6.5 | 22.0 | 11.0 | 4.0 | 0.75 | Red | IZUMI 3# | 1000 |
| 0.5~1.5mm² | KFSE112 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-3.5 | SVEL1.25-3.5 | 3.5 | 3.7 | 6.5 | 6.5 | 22.0 | 11.0 | 4.0 | 0.75 | Red | IZUMI 3# | 1000 |
| 0.5~1.5mm² | KFSE113 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-4 | SVES1.25-4 | 4 | 4.3 | 6.5 | 6.5 | 22.0 | 11.0 | 4.0 | 0.75 | Red | IZUMI 3# | 1000 |
| 0.5~1.5mm² | KFSE114 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-4 | SVEM1.25-4 | 4 | 4.3 | 7.0 | 6.5 | 22.0 | 11.0 | 4.0 | 0.75 | Red | IZUMI 3# | 1000 |
| 0.5~1.5mm² | KFSE115 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-4 | SVEL1.25-4 | 4 | 4.3 | 8.0 | 6.5 | 22.0 | 11.0 | 4.0 | 0.75 | Red | IZUMI 3# | 1000 |
| 0.5~1.5mm² | KFSE116 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-5 | SVES1.25-5 | 5 | 5.3 | 8.0 | 6.5 | 22.0 | 11.0 | 4.0 | 0.75 | Red | IZUMI 3# | 1000 |
| 0.5~1.5mm² | KFSE117 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-5 | SVEL1.25-5 | 5 | 5.3 | 9.5 | 6.5 | 22.0 | 11.0 | 4.0 | 0.75 | Red | IZUMI 3# | 1000 |
| 0.5~1.5mm² | KFSE118 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-6 | SVES1.25-6 | 6 | 6.4 | 9.5 | 6.5 | 22.0 | 11.0 | 4.0 | 0.75 | Red | IZUMI 3# | 1000 |
| 0.5~1.5mm² | KFSE119 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-6 | SVEL1.25-6 | 6 | 6.4 | 12.0 | 11.0 | 28.0 | 11.0 | 4.0 | 0.75 | Red | IZUMI 3# | 1000 |
| 1.5~2.5mm² | KFSE120 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-3 | SVE2-3 | 3 | 3.2 | 5.5 | 6.5 | 22.5 | 11.5 | 4.5 | 0.8 | Blue | IZUMI 4# | 1000 |
| 1.5~2.5mm² | KFSE121 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-3.5 | SVES2.-3.5 | 3.5 | 3.7 | 5.5 | 6.5 | 22.5 | 11.5 | 4.5 | 0.8 | Blue | IZUMI 4# | 1000 |
| 1.5~2.5mm² | KFSE122 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-3.5 | SVEL2-3.5 | 3.5 | 3.7 | 7.0 | 6.5 | 22.5 | 11.5 | 4.5 | 0.8 | Blue | IZUMI 4# | 1000 |
| 1.5~2.5mm² | KFSE123 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-4 | SVES2-4 | 4 | 4.3 | 6.5 | 6.5 | 22.5 | 11.5 | 4.5 | 0.8 | Blue | IZUMI 4# | 1000 |
| 1.5~2.5mm² | KFSE124 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-4 | SVEM2-4 | 4 | 4.3 | 7.0 | 6.5 | 22.5 | 11.5 | 4.5 | 0.8 | Blue | IZUMI 4# | 1000 |
| 1.5~2.5mm² | KFSE125 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-4 | SVEL2-4 | 4 | 4.3 | 8.0 | 6.5 | 22.5 | 11.5 | 4.5 | 0.8 | Blue | IZUMI 4# | 1000 |
| 1.5~2.5mm² | KFSE126 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-5 | SVES2-5 | 5 | 5.3 | 8.0 | 6.5 | 22.5 | 11.5 | 4.5 | 0.8 | Blue | IZUMI 4# | 1000 |
| 1.5~2.5mm² | KFSE127 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-5 | SVEL2-5 | 5 | 5.3 | 9.5 | 6.5 | 22.5 | 11.5 | 4.5 | 0.8 | Blue | IZUMI 4# | 1000 |
| 1.5~2.5mm² | KFSE128 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-6 | SVES2-6 | 6 | 6.4 | 9.5 | 6.5 | 22.5 | 11.5 | 4.5 | 0.8 | Blue | IZUMI 4# | 1000 |
| 1.5~2.5mm² | KFSE129 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-6 | SVEL2-6 | 6 | 6.4 | 12.0 | 11.0 | 28.5 | 11.5 | 4.5 | 0.8 | Blue | IZUMI 4# | 1000 |
| 4.0~6.0mm² | KFSE130 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-3.5 | SVE5.5-3.5 | 3.5 | 3.7 | 8.5 | 7.5 | 26.5 | 14.0 | 6.5 | 1.0 | Yellow | IZUMI 5# | 1000 |
| 4.0~6.0mm² | KFSE131 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-4 | SVES5.5-4 | 4 | 4.3 | 8.5 | 7.5 | 26.5 | 14.0 | 6.5 | 1.0 | Yellow | IZUMI 5# | 1000 |
| 4.0~6.0mm² | KFSE132 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-4 | SVEL5.5-4 | 4 | 4.3 | 9.5 | 7.5 | 26.5 | 14.0 | 6.5 | 1.0 | Yellow | IZUMI 5# | 1000 |
| 4.0~6.0mm² | KFSE133 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-5 | SVE5.5-5 | 5 | 5.3 | 9.0 | 7.5 | 26.5 | 14.0 | 6.5 | 1.0 | Yellow | IZUMI 5# | 1000 |
| 4.0~6.0mm² | KFSE134 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-6 | SVES5.5-6 | 6 | 6.4 | 9.0 | 7.5 | 26.5 | 14.0 | 6.5 | 1.0 | Yellow | IZUMI 5# | 1000 |
| 4.0~6.0mm² | KFSE135 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-6 | SVEL5.5-6 | 6 | 6.4 | 12.0 | 12.0 | 32.5 | 14.0 | 6.5 | 1.0 | Yellow | IZUMI 5# | 1000 |
| 4.0~6.0mm² | KFSE136 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-8 | SVE5.5-8 | 8 | 8.4 | 14.0 | 11.5 | 31.5 | 14.0 | 6.5 | 1.0 | Yellow | IZUMI 5# | 1000 |
Want to get a sample? Please fill in the form, leave your contact information and parameter information.
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions Inch | Color | Tool | PCS/Pack | ||||||
| USA | d2 | B | F | L | H | D | T | |||||||
| A.W.G. 22-16 | KFSE110 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-3 | SVE1.25-3 | #4 | 0.126 | 0.217 | 0.256 | 0.866 | 0.433 | 0.157 | 0.030 | Red | IZUMI 3# | 1000 |
| A.W.G. 22-16 | KFSE111 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-3.5 | SVES1.25-3.5 | #6 | 0.146 | 0.217 | 0.256 | 0.866 | 0.433 | 0.157 | 0.030 | Red | IZUMI 3# | 1000 |
| A.W.G. 22-16 | KFSE112 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-3.5 | SVEL1.25-3.5 | #6 | 0.146 | 0.256 | 0.256 | 0.866 | 0.433 | 0.157 | 0.030 | Red | IZUMI 3# | 1000 |
| A.W.G. 22-16 | KFSE113 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-4 | SVES1.25-4 | #8 | 0.169 | 0.256 | 0.256 | 0.866 | 0.433 | 0.157 | 0.030 | Red | IZUMI 3# | 1000 |
| A.W.G. 22-16 | KFSE114 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-4 | SVEM1.25-4 | #8 | 0.169 | 0.276 | 0.256 | 0.866 | 0.433 | 0.157 | 0.030 | Red | IZUMI 3# | 1000 |
| A.W.G. 22-16 | KFSE115 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-4 | SVEL1.25-4 | #8 | 0.169 | 0.315 | 0.256 | 0.866 | 0.433 | 0.157 | 0.030 | Red | IZUMI 3# | 1000 |
| A.W.G. 22-16 | KFSE116 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-5 | SVES1.25-5 | #10 | 0.209 | 0.315 | 0.256 | 0.866 | 0.433 | 0.157 | 0.030 | Red | IZUMI 3# | 1000 |
| A.W.G. 22-16 | KFSE117 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-5 | SVEL1.25-5 | #10 | 0.209 | 0.374 | 0.256 | 0.866 | 0.433 | 0.157 | 0.030 | Red | IZUMI 3# | 1000 |
| A.W.G. 22-16 | KFSE118 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-6 | SVES1.25-6 | 1/4" | 0.252 | 0.374 | 0.256 | 0.866 | 0.433 | 0.157 | 0.030 | Red | IZUMI 3# | 1000 |
| A.W.G. 22-16 | KFSE119 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-6 | SVEL1.25-6 | 1/4" | 0.252 | 0.472 | 0.433 | 1.102 | 0.433 | 0.157 | 0.030 | Red | IZUMI 3# | 1000 |
| A.W.G. 16-14 | KFSE120 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-3 | SVE2-3 | #4 | 0.126 | 0.217 | 0.256 | 0.886 | 0.453 | 0.177 | 0.031 | Blue | IZUMI 4# | 1000 |
| A.W.G. 16-14 | KFSE121 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-3.5 | SVES2.-3.5 | #6 | 0.146 | 0.217 | 0.256 | 0.886 | 0.453 | 0.177 | 0.031 | Blue | IZUMI 4# | 1000 |
| A.W.G. 16-14 | KFSE122 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-3.5 | SVEL2-3.5 | #6 | 0.146 | 0.276 | 0.256 | 0.886 | 0.453 | 0.177 | 0.031 | Blue | IZUMI 4# | 1000 |
| A.W.G. 16-14 | KFSE123 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-4 | SVES2-4 | #8 | 0.169 | 0.256 | 0.256 | 0.886 | 0.453 | 0.177 | 0.031 | Blue | IZUMI 4# | 1000 |
| A.W.G. 16-14 | KFSE124 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-4 | SVEM2-4 | #8 | 0.169 | 0.276 | 0.256 | 0.886 | 0.453 | 0.177 | 0.031 | Blue | IZUMI 4# | 1000 |
| A.W.G. 16-14 | KFSE125 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-4 | SVEL2-4 | #8 | 0.169 | 0.315 | 0.256 | 0.886 | 0.453 | 0.177 | 0.031 | Blue | IZUMI 4# | 1000 |
| A.W.G. 16-14 | KFSE126 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-5 | SVES2-5 | #10 | 0.209 | 0.315 | 0.256 | 0.886 | 0.453 | 0.177 | 0.031 | Blue | IZUMI 4# | 1000 |
| A.W.G. 16-14 | KFSE127 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-5 | SVEL2-5 | #10 | 0.209 | 0.374 | 0.256 | 0.886 | 0.453 | 0.177 | 0.031 | Blue | IZUMI 4# | 1000 |
| A.W.G. 16-14 | KFSE128 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-6 | SVES2-6 | 1/4" | 0.252 | 0.374 | 0.256 | 0.886 | 0.453 | 0.177 | 0.031 | Blue | IZUMI 4# | 1000 |
| A.W.G. 16-14 | KFSE129 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-6 | SVEL2-6 | 1/4" | 0.252 | 0.472 | 0.433 | 1.122 | 0.453 | 0.177 | 0.031 | Blue | IZUMI 4# | 1000 |
| A.W.G. 12-10 | KFSE130 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-3.5 | SVE5.5-3.5 | #6 | 0.146 | 0.335 | 0.295 | 1.043 | 0.551 | 0.256 | 0.039 | Yellow | IZUMI 5# | 1000 |
| A.W.G. 12-10 | KFSE131 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-4 | SVES5.5-4 | #8 | 0.169 | 0.335 | 0.295 | 1.043 | 0.551 | 0.256 | 0.039 | Yellow | IZUMI 5# | 1000 |
| A.W.G. 12-10 | KFSE132 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-4 | SVEL5.5-4 | #8 | 0.169 | 0.374 | 0.295 | 1.043 | 0.551 | 0.256 | 0.039 | Yellow | IZUMI 5# | 1000 |
| A.W.G. 12-10 | KFSE133 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-5 | SVE5.5-5 | #10 | 0.209 | 0.354 | 0.295 | 1.043 | 0.551 | 0.256 | 0.039 | Yellow | IZUMI 5# | 1000 |
| A.W.G. 12-10 | KFSE134 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-6 | SVES5.5-6 | 1/4" | 0.252 | 0.354 | 0.295 | 1.043 | 0.551 | 0.256 | 0.039 | Yellow | IZUMI 5# | 1000 |
| A.W.G. 12-10 | KFSE135 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-6 | SVEL5.5-6 | 1/4" | 0.252 | 0.472 | 0.472 | 1.28 | 0.551 | 0.256 | 0.039 | Yellow | IZUMI 5# | 1000 |
| A.W.G. 12-10 | KFSE136 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-8 | SVE5.5-8 | 5/16" | 0.331 | 0.551 | 0.453 | 1.24 | 0.551 | 0.256 | 0.039 | Yellow | IZUMI 5# | 1000 |
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions mm | Color | Tool | PCS/Pack | ||||||
| Meric | d2 | B | F | L | H | D | T | |||||||
| 0.5~1.5mm² | KFSE110 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-3 | SVE1.25-3 | 3 | 3.2 | 5.5 | 6.5 | 22.0 | 11.0 | 4.0 | 0.75 | Red | IZUMI 3# | 1000 |
| 0.5~1.5mm² | KFSE111 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-3.5 | SVES1.25-3.5 |
3.5 |
3.7 | 5.5 | 6.5 | 22.0 | 11.0 | 4.0 | 0.75 | Red | IZUMI 3# | 1000 |
| 0.5~1.5mm² | KFSE112 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-3.5 | SVEL1.25-3.5 | 3.5 | 3.7 | 6.5 | 6.5 | 22.0 | 11.0 | 4.0 | 0.75 | Red | IZUMI 3# | 1000 |
| 0.5~1.5mm² | KFSE113 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-4 | SVES1.25-4 | 4 | 4.3 | 6.5 | 6.5 | 22.0 | 11.0 | 4.0 | 0.75 | Red | IZUMI 3# | 1000 |
| 0.5~1.5mm² | KFSE114 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-4 | SVEM1.25-4 | 4 | 4.3 | 7.0 | 6.5 | 22.0 | 11.0 | 4.0 | 0.75 | Red | IZUMI 3# | 1000 |
| 0.5~1.5mm² | KFSE115 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-4 | SVEL1.25-4 | 4 | 4.3 | 8.0 | 6.5 | 22.0 | 11.0 | 4.0 | 0.75 | Red | IZUMI 3# | 1000 |
| 0.5~1.5mm² | KFSE116 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-5 | SVES1.25-5 | 5 | 5.3 | 8.0 | 6.5 | 22.0 | 11.0 | 4.0 | 0.75 | Red | IZUMI 3# | 1000 |
| 0.5~1.5mm² | KFSE117 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-5 | SVEL1.25-5 | 5 | 5.3 | 9.5 | 6.5 | 22.0 | 11.0 | 4.0 | 0.75 | Red | IZUMI 3# | 1000 |
| 0.5~1.5mm² | KFSE118 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-6 | SVES1.25-6 | 6 | 6.4 | 9.5 | 6.5 | 22.0 | 11.0 | 4.0 | 0.75 | Red | IZUMI 3# | 1000 |
| 0.5~1.5mm² | KFSE119 | 22-16 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals1.25-6 | SVEL1.25-6 | 6 | 6.4 | 12.0 | 11.0 | 28.0 | 11.0 | 4.0 | 0.75 | Red | IZUMI 3# | 1000 |
| 1.5~2.5mm² | KFSE120 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-3 | SVE2-3 | 3 | 3.2 | 5.5 | 6.5 | 22.5 | 11.5 | 4.5 | 0.8 | Blue | IZUMI 4# | 1000 |
| 1.5~2.5mm² | KFSE121 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-3.5 | SVES2.-3.5 | 3.5 | 3.7 | 5.5 | 6.5 | 22.5 | 11.5 | 4.5 | 0.8 | Blue | IZUMI 4# | 1000 |
| 1.5~2.5mm² | KFSE122 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-3.5 | SVEL2-3.5 | 3.5 | 3.7 | 7.0 | 6.5 | 22.5 | 11.5 | 4.5 | 0.8 | Blue | IZUMI 4# | 1000 |
| 1.5~2.5mm² | KFSE123 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-4 | SVES2-4 | 4 | 4.3 | 6.5 | 6.5 | 22.5 | 11.5 | 4.5 | 0.8 | Blue | IZUMI 4# | 1000 |
| 1.5~2.5mm² | KFSE124 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-4 | SVEM2-4 | 4 | 4.3 | 7.0 | 6.5 | 22.5 | 11.5 | 4.5 | 0.8 | Blue | IZUMI 4# | 1000 |
| 1.5~2.5mm² | KFSE125 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-4 | SVEL2-4 | 4 | 4.3 | 8.0 | 6.5 | 22.5 | 11.5 | 4.5 | 0.8 | Blue | IZUMI 4# | 1000 |
| 1.5~2.5mm² | KFSE126 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-5 | SVES2-5 | 5 | 5.3 | 8.0 | 6.5 | 22.5 | 11.5 | 4.5 | 0.8 | Blue | IZUMI 4# | 1000 |
| 1.5~2.5mm² | KFSE127 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-5 | SVEL2-5 | 5 | 5.3 | 9.5 | 6.5 | 22.5 | 11.5 | 4.5 | 0.8 | Blue | IZUMI 4# | 1000 |
| 1.5~2.5mm² | KFSE128 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-6 | SVES2-6 | 6 | 6.4 | 9.5 | 6.5 | 22.5 | 11.5 | 4.5 | 0.8 | Blue | IZUMI 4# | 1000 |
| 1.5~2.5mm² | KFSE129 | 16-14 AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals2-6 | SVEL2-6 | 6 | 6.4 | 12.0 | 11.0 | 28.5 | 11.5 | 4.5 | 0.8 | Blue | IZUMI 4# | 1000 |
| 4.0~6.0mm² | KFSE130 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-3.5 | SVE5.5-3.5 | 3.5 | 3.7 | 8.5 | 7.5 | 26.5 | 14.0 | 6.5 | 1.0 | Yellow | IZUMI 5# | 1000 |
| 4.0~6.0mm² | KFSE131 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-4 | SVES5.5-4 | 4 | 4.3 | 8.5 | 7.5 | 26.5 | 14.0 | 6.5 | 1.0 | Yellow | IZUMI 5# | 1000 |
| 4.0~6.0mm² | KFSE132 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-4 | SVEL5.5-4 | 4 | 4.3 | 9.5 | 7.5 | 26.5 | 14.0 | 6.5 | 1.0 | Yellow | IZUMI 5# | 1000 |
| 4.0~6.0mm² | KFSE133 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-5 | SVE5.5-5 | 5 | 5.3 | 9.0 | 7.5 | 26.5 | 14.0 | 6.5 | 1.0 | Yellow | IZUMI 5# | 1000 |
| 4.0~6.0mm² | KFSE134 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-6 | SVES5.5-6 | 6 | 6.4 | 9.0 | 7.5 | 26.5 | 14.0 | 6.5 | 1.0 | Yellow | IZUMI 5# | 1000 |
| 4.0~6.0mm² | KFSE135 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-6 | SVEL5.5-6 | 6 | 6.4 | 12.0 | 12.0 | 32.5 | 14.0 | 6.5 | 1.0 | Yellow | IZUMI 5# | 1000 |
| 4.0~6.0mm² | KFSE136 | 12-10AWG Vinyl-Insulated Single Crimp (Easy Entry) Spade Terminals5.5-8 | SVE5.5-8 | 8 | 8.4 | 14.0 | 11.5 | 31.5 | 14.0 | 6.5 | 1.0 | Yellow | IZUMI 5# | 1000 |
You can tick the products you need and communicate with us in the message board.
