Brand |
KF |
|
Finish/Coating |
Tinned |
|
Base Materials |
Brass,PVC |
|
Insulation Material |
N/A |
|
Brazed |
Seam |
|
Wire/Cable Type |
Regular Wire |
|
Color Code |
Standard |
|
MOQ |
1000Pcs/item |
|
Payment Terms |
Based on orders |
|
Delivery |
FOB/CIF/DDP |
|
Spec (American AWG) |
22-16 | 16-14 | 12-10 |
|
Spec (JIS AWG) |
1.25 | 2 | 5.5 |
|
Spec (DIN AWG) |
1 | 2.5 | 4.0-6.0 |
|
Spec (GB mm2) |
0.5-1.5 | 2.5 | 6 |
|
Max Current |
10 | 15 | 24 |
| Operating Voltage | 600V | ||
| Temperature Withstand | 75℃ | ||
You can tick the products you need and communicate with us in the message board.
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions Inch | Color | Tool | PCS/Pack | |||||
| USA | B | d | D | L | H | Thickness | |||||||
| A.W.G. 22-16 | KFQVM10 | 22-16 AWG Vinyl-Insulated Male Quick Disconnectors MDD 1.25-110(5) | MDD 1.25-110(5) | 0.110 | 0.079 | 0.138 | 0.748 | 0.394 | 0.020 | Red | IZUMI 3# | 1000 | |
| A.W.G. 22-16 | KFQVM11 | 22-16 AWG Vinyl-Insulated Male Quick Disconnectors MDD 1.25-110(8) | MDD 1.25-110(8) | 0.110 | 0.079 | 0.177 | 0.748 | 0.394 | 0.031 | Red | IZUMI 3# | 1000 | |
| A.W.G. 22-16 | KFQVM12 | 22-16 AWG Vinyl-Insulated Male Quick Disconnectors MDD 1.25-187(5) | MDD 1.25-187(5) | 0.187 | 0.079 | 0.138 | 0.787 | 0.394 | 0.020 | Red | IZUMI 3# | 1000 | |
| A.W.G. 22-16 | KFQVM13 | 22-16 AWG Vinyl-Insulated Male Quick Disconnectors MDD 1.25-187(8) | MDD 1.25-110(8) | 0.187 | 0.079 | 0.177 | 0.787 | 0.394 | 0.031 | Red | IZUMI 3# | 1000 | |
| A.W.G. 22-16 | KFQVM14 | 22-16 AWG Vinyl-Insulated Male Quick Disconnectors MDD 1.25-250 | MDD 1.25-250 | 0.250 | 0.079 | 0.157 | 0.827 | 0.394 | 0.031 | Red | IZUMI 3# | 1000 | |
| A.W.G. 16～14 | KFQVM20 | 16-14 AWG Vinyl-Insulated Male Quick Disconnectors MDD 2-187(5) | MDD 2-187(5) | 0.187 | 0.098 | 0.177 | 0.787 | 0.394 | 0.020 | Blue | IZUMI 4# | 1000 | |
| A.W.G. 16～14 | KFQVM21 | 16-14 AWG Vinyl-Insulated Male Quick Disconnectors MDD 2-187(8) | MDD 2-187(8) | 0.187 | 0.098 | 0.197 | 0.787 | 0.394 | 0.031 | Blue | IZUMI 4# | 1000 | |
| A.W.G. 16～14 | KFQVM22 | 16-14 AWG Vinyl-Insulated Male Quick Disconnectors MDD 2-187(8) | MDD 2-250 | 0.250 | 0.098 | 0.177 | 0.827 | 0.394 | 0.031 | Blue | IZUMI 4# | 1000 | |
| A.W.G. 12～10 | KFQVM30 | 16-14 AWG Vinyl-Insulated Male Quick Disconnectors MDD 5.5-250 | MDD 5.5-250 | 0.250 | 0.138 | 0.217 | 0.945 | 0.512 | 0.031 | Yellow | IZUMI 5# | 500 | |
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions mm | Color | Tool | PCS/Pack | |||||
| Meric | B | d | D | L | H | Thickness | |||||||
| 0.5～1.5mm² | KFQVM10 | 22-16 AWG Vinyl-Insulated Male Quick Disconnectors MDD 1.25-110(5) | MDD 1.25-110(5) | 2.8 | 2.0 | 3.5 | 19.0 | 10.00 | 0.50 | Red | IZUMI 3# | 1000 | |
| 0.5～1.5mm² | KFQVM11 | 22-16 AWG Vinyl-Insulated Male Quick Disconnectors MDD 1.25-110(8) | MDD 1.25-110(8) | 2.8 | 2.0 | 4.5 | 19.0 | 10.00 | 0.80 | Red | IZUMI 3# | 1000 | |
| 0.5～1.5mm² | KFQVM12 | 22-16 AWG Vinyl-Insulated Male Quick Disconnectors MDD 1.25-187(5) | MDD 1.25-187(5) | 4.8 | 2.0 | 3.5 | 20.0 | 10.00 | 0.50 | Red | IZUMI 3# | 1000 | |
| 0.5～1.5mm² | KFQVM13 | 22-16 AWG Vinyl-Insulated Male Quick Disconnectors MDD 1.25-187(8) | MDD 1.25-110(8) | 4.8 | 2.0 | 4.5 | 20.0 | 10.00 | 0.80 | Red | IZUMI 3# | 1000 | |
| 0.5～1.5mm² | KFQVM14 | 22-16 AWG Vinyl-Insulated Male Quick Disconnectors MDD 1.25-250 | MDD 1.25-250 | 6.4 | 2.0 | 4.0 | 21.0 | 10.00 | 0.80 | Red | IZUMI 3# | 1000 | |
| 1.5～2.5mm² | KFQVM20 | 16-14 AWG Vinyl-Insulated Male Quick Disconnectors MDD 2-187(5) | MDD 2-187(5) | 4.8 | 2.5 | 4.5 | 20.0 | 10.00 | 0.50 | Blue | IZUMI 4# | 1000 | |
| 1.5～2.5mm² | KFQVM21 | 16-14 AWG Vinyl-Insulated Male Quick Disconnectors MDD 2-187(8) | MDD 2-187(8) | 4.8 | 2.5 | 5.0 | 20.0 | 10.00 | 0.80 | Blue | IZUMI 4# | 1000 | |
| 1.5～2.5mm² | KFQVM22 | 16-14 AWG Vinyl-Insulated Male Quick Disconnectors MDD 2-187(8) | MDD 2-250 | 6.4 | 2.5 | 4.5 | 21.0 | 10.00 | 0.80 | Blue | IZUMI 4# | 1000 | |
| 4～6mm² | KFQVM30 | 16-14 AWG Vinyl-Insulated Male Quick Disconnectors MDD 5.5-250 | MDD 5.5-250 | 6.4 | 3.5 | 5.5 | 24.0 | 13.00 | 0.80 | Yellow | IZUMI 5# | 500 | |
Want to get a sample? Please fill in the form, leave your contact information and parameter information.
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions Inch | Color | Tool | PCS/Pack | |||||
| USA | B | d | D | L | H | Thickness | |||||||
| A.W.G. 22-16 | KFQVM10 | 22-16 AWG Vinyl-Insulated Male Quick Disconnectors MDD 1.25-110(5) | MDD 1.25-110(5) | 0.110 | 0.079 | 0.138 | 0.748 | 0.394 | 0.020 | Red | IZUMI 3# | 1000 | |
| A.W.G. 22-16 | KFQVM11 | 22-16 AWG Vinyl-Insulated Male Quick Disconnectors MDD 1.25-110(8) | MDD 1.25-110(8) | 0.110 | 0.079 | 0.177 | 0.748 | 0.394 | 0.031 | Red | IZUMI 3# | 1000 | |
| A.W.G. 22-16 | KFQVM12 | 22-16 AWG Vinyl-Insulated Male Quick Disconnectors MDD 1.25-187(5) | MDD 1.25-187(5) | 0.187 | 0.079 | 0.138 | 0.787 | 0.394 | 0.020 | Red | IZUMI 3# | 1000 | |
| A.W.G. 22-16 | KFQVM13 | 22-16 AWG Vinyl-Insulated Male Quick Disconnectors MDD 1.25-187(8) | MDD 1.25-110(8) | 0.187 | 0.079 | 0.177 | 0.787 | 0.394 | 0.031 | Red | IZUMI 3# | 1000 | |
| A.W.G. 22-16 | KFQVM14 | 22-16 AWG Vinyl-Insulated Male Quick Disconnectors MDD 1.25-250 | MDD 1.25-250 | 0.250 | 0.079 | 0.157 | 0.827 | 0.394 | 0.031 | Red | IZUMI 3# | 1000 | |
| A.W.G. 16～14 | KFQVM20 | 16-14 AWG Vinyl-Insulated Male Quick Disconnectors MDD 2-187(5) | MDD 2-187(5) | 0.187 | 0.098 | 0.177 | 0.787 | 0.394 | 0.020 | Blue | IZUMI 4# | 1000 | |
| A.W.G. 16～14 | KFQVM21 | 16-14 AWG Vinyl-Insulated Male Quick Disconnectors MDD 2-187(8) | MDD 2-187(8) | 0.187 | 0.098 | 0.197 | 0.787 | 0.394 | 0.031 | Blue | IZUMI 4# | 1000 | |
| A.W.G. 16～14 | KFQVM22 | 16-14 AWG Vinyl-Insulated Male Quick Disconnectors MDD 2-187(8) | MDD 2-250 | 0.250 | 0.098 | 0.177 | 0.827 | 0.394 | 0.031 | Blue | IZUMI 4# | 1000 | |
| A.W.G. 12～10 | KFQVM30 | 16-14 AWG Vinyl-Insulated Male Quick Disconnectors MDD 5.5-250 | MDD 5.5-250 | 0.250 | 0.138 | 0.217 | 0.945 | 0.512 | 0.031 | Yellow | IZUMI 5# | 500 | |
| Wire Range | SKU# | Description | MFG# | Stud Size | Dimensions mm | Color | Tool | PCS/Pack | |||||
| Meric | B | d | D | L | H | Thickness | |||||||
| 0.5～1.5mm² | KFQVM10 | 22-16 AWG Vinyl-Insulated Male Quick Disconnectors MDD 1.25-110(5) | MDD 1.25-110(5) | 2.8 | 2.0 | 3.5 | 19.0 | 10.00 | 0.50 | Red | IZUMI 3# | 1000 | |
| 0.5～1.5mm² | KFQVM11 | 22-16 AWG Vinyl-Insulated Male Quick Disconnectors MDD 1.25-110(8) | MDD 1.25-110(8) | 2.8 | 2.0 | 4.5 | 19.0 | 10.00 | 0.80 | Red | IZUMI 3# | 1000 | |
| 0.5～1.5mm² | KFQVM12 | 22-16 AWG Vinyl-Insulated Male Quick Disconnectors MDD 1.25-187(5) | MDD 1.25-187(5) | 4.8 | 2.0 | 3.5 | 20.0 | 10.00 | 0.50 | Red | IZUMI 3# | 1000 | |
| 0.5～1.5mm² | KFQVM13 | 22-16 AWG Vinyl-Insulated Male Quick Disconnectors MDD 1.25-187(8) | MDD 1.25-110(8) | 4.8 | 2.0 | 4.5 | 20.0 | 10.00 | 0.80 | Red | IZUMI 3# | 1000 | |
| 0.5～1.5mm² | KFQVM14 | 22-16 AWG Vinyl-Insulated Male Quick Disconnectors MDD 1.25-250 | MDD 1.25-250 | 6.4 | 2.0 | 4.0 | 21.0 | 10.00 | 0.80 | Red | IZUMI 3# | 1000 | |
| 1.5～2.5mm² | KFQVM20 | 16-14 AWG Vinyl-Insulated Male Quick Disconnectors MDD 2-187(5) | MDD 2-187(5) | 4.8 | 2.5 | 4.5 | 20.0 | 10.00 | 0.50 | Blue | IZUMI 4# | 1000 | |
| 1.5～2.5mm² | KFQVM21 | 16-14 AWG Vinyl-Insulated Male Quick Disconnectors MDD 2-187(8) | MDD 2-187(8) | 4.8 | 2.5 | 5.0 | 20.0 | 10.00 | 0.80 | Blue | IZUMI 4# | 1000 | |
| 1.5～2.5mm² | KFQVM22 | 16-14 AWG Vinyl-Insulated Male Quick Disconnectors MDD 2-187(8) | MDD 2-250 | 6.4 | 2.5 | 4.5 | 21.0 | 10.00 | 0.80 | Blue | IZUMI 4# | 1000 | |
| 4～6mm² | KFQVM30 | 16-14 AWG Vinyl-Insulated Male Quick Disconnectors MDD 5.5-250 | MDD 5.5-250 | 6.4 | 3.5 | 5.5 | 24.0 | 13.00 | 0.80 | Yellow | IZUMI 5# | 500 | |
You can tick the products you need and communicate with us in the message board.
